Wintech's metalized films are constructed by vacuum depositing aluminum onto sheets of polyester. By controlling minute details in this process, we are able to offer widely varying combinations that result in different colors and optical densities. Our colored metalized films are created by combining elements of our metallization process with traditional film dying techniques. The result is a unique film with color on one side and a metallic sheen on the other.
PRODUCT VLT VLR TST TSR TSA SC SHGC E UVR TSER
Natural 05 6 13 38 14 48 0.57 0.50 - 99 50
Natural 10 13 14 35 16 49 0.54 0.47 - 99 53
Natural 20 23 19 35 22 43 0.52 0.45 - 99 55
Natural 35 46 20 44 22 34 0.60 0.52 - 99 48
Natural 50 54 10 58 10 32 0.75 0.66 - 99 34
Silver 15 18 65 11 65 24 0.24 0.21 - 99 79
Silver 35 39 37 32 40 28 0.44 0.38 - 99 62
Silver 50 52 20 46 26 28 0.60 0.52 - 99 48
Silver 65 65 13 61 13 26 0.77 0.67 - 99 33
PR Blue 15 13 26 13 49 38 0.25 0.21 - 99 79
PR Green 15 15 22 15 38 47 0.30 0.26 - 99 74
PR Bronze 15 10 21 12 42 46 0.26 0.23 - 99 77
PR Gold 15 19 44 16 52 32 0.26 0.23 - 99 77
PR Gray 10 9 14 12 35 53 0.28 0.25 - 99 75

  • VLT: Visible Light Transmission
  • VLR: Visible Light Reflectance
  • TST: Total Solar Transmittance
  • TSR: Total Solar Reflectance
  • SC: Shading Coefficient
  • SHGC: Solar Heat Gain Coefficient
  • E: Emissivity
  • UVR: Ultraviolet (UV) Rejection
  • TSER: Total Solar Energy Rejection
All data values above are representative, and expressed for comparison purpose only.
